Lithophane LED Backlight Circuit Board Kit

Description



Introduction

Bring your images to life! By combining 3D printing technology with the PLA CMYK Lithophane Bundle, you can effortlessly design and create stunning Lithophane artworks at home. Simply use the Lithophane LED Backlight Board Kit to illuminate your creations and make them truly shine.

Start creating your lithophane with Make My Lithophane today! Make My Lithophane is also available in Bambu Handy now.





.pct_productFeatureList { display: flex; justify-content: flex-start; align-items: center; flex-wrap: wrap; column-gap: 50px; row-gap: 5px; } .pct_productFeatureList li { padding: 0; } @media (min-width: 640px) { .pct_productFeatureList { display: flex; justify-content: center; align-items: center; flex-wrap: wrap; column-gap: 50px; row-gap: 0px; } }

Bring colors to your lithophane

6 Litophane Styles to Choose From

There are six types of Lithophane available on the Make My Lithophane page. Among them, Mono Lithophane with Frame and Colorful Lithophane are compatible with the Lithophane LED Backlight Board Kit. If you want to bring color to your Lithophane, please choose the Colorful Lithophane with Frame option.


Documentation

Specification 3D Model Application Instruction

.pct_hardware-tableList-t-icpc { padding: ‘0 20px’ } .pct_hardware-tableList { width: 100%; row-gap: 15px !important; column-gap: 15px !important; } .pct_hardware-tableList .pct_ic-p { overflow: hidden; } .pct_hardware-tableList .pct_st-tbc .pct_tb .pct_td { border-color: #ADADAD; } @media (min-width: 640px) { .pct_hardware-tableList-t-icpc { padding: 0px !important } .pct_hardware-tableList { width: 100%; row-gap: 15px; column-gap: 15px; } .pct_hardware-tableList .pct_st-tbc .pct_tb .pct_td { height: 50px; } }

Basic Information

Number of LEDs	48/pcs
Connector Model	PH2.0 x 2

Voltage	5V
Current	2A

Difference between  CMYK Backlight Board  And This Kit

Product	CMYK Backlight Board	Lithophane LED Backlight Board （2PCS）	Lithophane LED Backlight Board （4PCS）
Size support	Single size	Single size	Multiple sizes supported
Lithophane Size(including margin)	144 x 108 x 2.7 mm	2PCS：106 x 156 x （2.5-3.2）mm	2PCS：106 x 156 x （2.5-3.2）mm OR 3PCS：156 x 156 x （2.5-3.2）mm OR 4PCS：156 x 207 x（2.5-3.2）mm
Assemble  Methods	One	Two	Five
Design	Fixed size	Modular design
Dimming function	Fixed	Adjustable (long-press dimming)
Power cable	Not included	Inclued
Ideal for	Users seeking a straightforward solution	Users who require flexibility and customization

In the Box

Item for Lithophane LED Backlight Board Kit (2PCS) – KC009	Qty
LED Backlight Board	2PCS
PH2.0 Power Connection Cable	1PCS
USB to PH2.0 Power Cable with ON/OFF Switch	1PCS

Item for Lithophane LED Backlight Board Kit (4PCS) – KC010	Qty
LED Backlight Board	4PCS
PH2.0 Power Connection Cable	3PCS
USB to PH2.0 Power Cable with ON/OFF Switch	1PCS

Considerations

• Smaller nozzle sizes and lower layer heights are essential to achieve better printing results. We suggest using 0.2mm or 0.4mm nozzle sizes and layer heights between 0.08mm and 0.12mm. If you use other tools to generate the lithophane model, you may need to configure the print profile to optimize the result. Please check CMYK Lithophane Printing Guide on Wiki.

• Due to the limitations of printing layers and resolution, there may be some color deviation between the actual image and the lithophane prints.

• To prevent warping, the recommended heated bed temperature is between 45-50℃.
